MASE MARINER GENSET 904 - 60 Hz - 1800 RPM 8500 Watt Marine Diesel Generator

$9,989.99 $13,999.95

Free Shipping
Lowest Pricing
No Sales Tax
Premium Authorized Dealer

Added to wishlist

MASE MARINER GENSET 904 - 60 Hz - 1800 RPM 8500 Watt Marine Diesel Generator

$9,989.99 $13,999.95

.. people are viewing this

.. Visitor Right Now

4 Great reasons to buy from us:

Description

This generator is no longer in production. Please refer to the replacement model below: The MASE Mariner 906. This is the same 8500 watt generator with some upgrades.

Click here for the Mariner 906 S

The highest quality, most reliable marine generators on the water. This 8500 watt marine diesel generator will supply all the power you need. This reliable boat generator is Powered by Yanmar diesel, Mase Generators marine gensets are specifically designed and manufactured for installation on-board boats. The diesel generators assure shipbuilders and end users easy installation with high efficiency and performance. Designed for the special demands of the marine environment, Mase Generators marine gensets feature low sound levels and very low emissions.

Hz: 60
Max power single-phase range (KW): 8,5
Series: Mariner
Frame: Soundproof
Engine: Yanmar
R.p.m.: 1800

CBU control panel (Mod-Bus transmission Unit)

New design, latest technology, big display and soft touch buttons for quick menu navigation, start and stop procedure, IP54 protection grade. Very compact MASTER CBU 93x93mm (3.66x3.66 in). CBU has many functions for easy monitoring of the generator:

ON/OFF/START/STOP/MENU
Digital hour-meter, Main voltage, Generator Battery voltage, external battery pack voltage, Frequency, Service time, Event list of last 10 alarms and
13 different alarms icons
485 Mod-Bus connector for monitoring generator by boat main control

Engine	60 Hz
Model	YANMAR 3TNV80F-NGGE
Type	Diesel 4 stroke
Cylinders (nr.)	3
Cylinder block material	Cast iron
Bore (mm - in.)	80
Stroke (mm - in.)	84
Displacement (cc - cu.in.)	1267
Power (hp)	13,8
Rated rpm	1800
Combustion system	Indirect
Engine head material	Cast iron
Speed governor	Centrifugal mechanical
Lubrication system	Forced
Oil sump capacity (L - qt.)	3,4
Engine stop system	Stop solenoid
Fuel pump	Electric
Fuel pump discharge (cm - in.)	70
Full load consumption (L/h - qt/h)	3,2 - 3,4
Starting battery (Ah-V)	45 - 12
Battery charger (Ah-V)	40 - 12
Starter (kW-V)	0,8 - 12
Max. inclination	30°
Water pump flow (L/min - gal/min)	24

Engine

Alternator	60 Hz
Type	Synchronous, 4-poles, self-excited
Cooling	Air
Voltage (V)	120 - 240
Frequency (Hz)	60
Current (A)	70,8 - 35,4
Max. power (kW)	8,5
Continuous power (kW)	7,7
Power factor ( cos ø )	1
Insulating class	H
Voltage stability	±2%
Frequency stability	±5%

Easy access in case of maintenance to the feeding system and lubrication, of the sea/water pump and the air filter.

Safety stop in case of low oil pressure

Safety stop in case high water/exhaust gas temperature. Oil and fuel filters of easy access.

Alternator

Synchronous, 4 poles, self-regulated, brush less self-excited.
Rotor and stator epoxy resin coated against external
Rotor dinamically
Insulation class

Soundproof cabin

The structure is composed by a steel mainframe and painted pa- nels of aluminum 5754 type, that has a very high resistance to external agents.

Thanks to this structure, soundproof cabin has a limited weight and an easy accessibility in case of maintenance services, also if installed in narrow places.

Cooling system

The cooling of the engine is based on a closed inner flow of coolant. The system is based on a cupronickel heat exchange seawater/coolant type, where the thermal exchange occurs between coolant and seawater. Two separate pumps contribute to the flow of the coolant and the sea water.

	60 Hz
Dimensions (Leng. x Width x Height)	945mm x	535mm	x 624mm
Dimensions (Leng. x Width x Height)	37,2in x	21,1in	x 24,6in
Weight	295	-	650,36
Noise level emission	51 dBA @ 7mt

FITTINGS (optional)

- EXHAUST COMPONENTS KIT

SIPHON BREAK
WATER-GAS SEPARATOR KIT

-

SLAVE CBU CONTROL PANEL WITH A SHIELD CONNECTING CABLE 10 Mt. ( 32.8 ft ) LONG
