Cummins Commercial SD 7.5 HDKAL 7.5kW Commercial Mobile Diesel Generator
The Cummins Commercial SD 7.5 HDKAL is a commercial-grade 7.5kW commercial mobile diesel generator designed for demanding specialty vehicle and mobile equipment applications. Available in four factory configurations, the series offers single-phase and three-phase output, multiple voltage arrangements, and either pusher or suction cooling airflow.
Choose from the 7.5HDKAL-1, 7.5HDKAL-2, 7.5HDKAL-3, or 7.5HDKAL-5 based on the voltage, phase, amperage, and cooling configuration required for your installation. Each model delivers 7,500 watts at 60 Hz and is engineered for dependable onboard power in commercial mobile environments.
Select the option on this page listed 1-4 below
Available Configurations
| Item Number | Model | Fuel | Watts | Voltage | Phase | Amps | Fan |
|---|---|---|---|---|---|---|---|
| A061A428 | 7.5HDKAL-1 | Diesel | 7,500 | 120/240V | Single Phase | 63/31A | Pusher |
| A061A430 | 7.5HDKAL-2 | Diesel | 7,500 | 120/240V | Single Phase | 63/31A | Suction |
| A060C031 | 7.5HDKAL-3 | Diesel | 7,500 | 12-Lead Reconnectable | Three Phase | See Voltage Configuration Chart | Pusher |
| A063B620 | 7.5HDKAL-5 | Diesel | 7,500 | 100/200V | Single Phase | 75/38A | Pusher |
The 7.5HDKAL-3 three-phase model is connected for 120/240V delta output at the factory and can be reconfigured for a broader range of voltage applications. The circuit breaker must be selected for the final voltage configuration and is shipped loose.
Built for Commercial Mobile Applications
The Cummins Commercial SD 7.5 HDKAL is engineered for commercial mobile genset installations where reliable onboard diesel power is essential. It is well suited for specialty vehicles and mobile equipment that require dependable electrical output for HVAC systems, tools, pumps, refrigeration, communication equipment, lighting, battery charging, and other demanding loads.
Typical applications include:
- Commercial service trucks
- Utility and municipal vehicles
- Emergency response vehicles
- Mobile medical and laboratory vehicles
- Food trucks and concession trailers
- Mobile workshops
- Broadcast and communications vehicles
- Contractor and construction vehicles
- Specialty trailers
- Mobile command centers
- Fleet vehicles
- Industrial mobile equipment
Four Configurations for Different Installation Requirements
A061A428 – Model 7.5HDKAL-1
The Cummins A061A428, model 7.5HDKAL-1, delivers 7,500 watts at 120/240V, 60 Hz, single phase. It provides 63/31 amps and uses a pusher-style cooling fan. This model is designed for conventional North American split-phase commercial mobile power systems that require pusher airflow.
- 7,500-watt output
- 120/240V
- Single phase
- 63/31 amps
- Pusher fan
- Diesel fuel
A061A430 – Model 7.5HDKAL-2
The Cummins A061A430, model 7.5HDKAL-2, also delivers 7,500 watts at 120/240V, 60 Hz, single phase, with 63/31 amps. Its primary difference is the suction-style cooling fan, making it appropriate for commercial mobile installations that require air to be drawn through the generator in the opposite direction.
- 7,500-watt output
- 120/240V
- Single phase
- 63/31 amps
- Suction fan
- Diesel fuel
A060C031 – Model 7.5HDKAL-3
The Cummins A060C031, model 7.5HDKAL-3, is the three-phase configuration in the Commercial SD 7.5 HDKAL family. Its 12-lead reconnectable alternator supports a wider range of voltage applications for specialized commercial mobile equipment and three-phase electrical systems.
- 7,500-watt output
- 12-lead reconnectable alternator
- Three-phase output
- Factory-connected for 120/240V delta
- Pusher fan
- Diesel fuel
- Circuit breaker selected according to final voltage configuration
A063B620 – Model 7.5HDKAL-5
The Cummins A063B620, model 7.5HDKAL-5, delivers 7,500 watts at 100/200V, 60 Hz, single phase. It provides 75/38 amps and uses a pusher-style cooling fan. This configuration is intended for specialty commercial mobile equipment built around a 100/200V electrical system.
- 7,500-watt output
- 100/200V
- Single phase
- 75/38 amps
- Pusher fan
- Diesel fuel
Commercial-Grade Diesel Power
Built with Cummins engineering, the Commercial SD 7.5 HDKAL is designed to deliver dependable power in demanding mobile environments. Its diesel platform is suited for applications that require durability, stable voltage and frequency, long service life, and reliable operation under varying electrical loads.
- 7.5kW commercial mobile diesel generator
- 7,500 watts of rated output
- 60 Hz operation
- Single-phase and three-phase options
- 120/240V, 100/200V, and reconnectable voltage options
- Pusher and suction cooling configurations
- Commercial-duty construction
- Designed for specialty vehicle installations
- Multiple configurations for installation flexibility
- Reliable onboard power for professional equipment
Technical Specifications
| Manufacturer | Cummins |
| Product Series | Commercial SD 7.5 HDKAL |
| Generator Classification | Commercial Mobile Generator |
| Fuel Type | Diesel |
| Rated Output | 7,500 Watts |
| Frequency | 60 Hz |
| Available Voltages | 120/240V, 100/200V, or 12-Lead Reconnectable |
| Available Phase Configurations | Single Phase or Three Phase |
| Cooling Fan Options | Pusher or Suction |
| Application | Commercial Mobile |
How to Choose the Correct Cummins 7.5 HDKAL Model
Select the correct configuration according to the voltage, phase, amperage, and cooling airflow requirements of your commercial mobile installation:
- Choose A061A428 / 7.5HDKAL-1 for 120/240V single-phase power with a pusher fan.
- Choose A061A430 / 7.5HDKAL-2 for 120/240V single-phase power with a suction fan.
- Choose A060C031 / 7.5HDKAL-3 for a reconnectable three-phase electrical system with a pusher fan.
- Choose A063B620 / 7.5HDKAL-5 for 100/200V single-phase power with a pusher fan.
The required fan direction depends on the compartment design and intended airflow path. Voltage and phase must match the electrical system being powered. Installation planning should be completed by a qualified generator installer familiar with Cummins commercial mobile generator requirements.
Why Buy from AllProGenerators?
AllProGenerators.com specializes in commercial mobile generators, RV generators, marine generators, standby generators, and portable power equipment. Our USA-based team can help confirm the correct Cummins item number, model, voltage, phase, and fan configuration before your order ships.
- Authorized generator dealer
- USA-based expert support
- Commercial mobile generator specialists
- Competitive pricing
- Nationwide shipping
- Help selecting the correct model and configuration
- Knowledgeable support before and after the sale
Order the Cummins Commercial SD 7.5 HDKAL Commercial Mobile Generator
Select the required Cummins Commercial SD 7.5 HDKAL configuration from the product options above. Carefully verify the item number, model, voltage, phase, amperage, and fan direction before ordering. Contact AllProGenerators for assistance matching the correct 7.5kW commercial mobile diesel generator to your vehicle or equipment application.
